Diamond Products Core Cut CC3740E3-36″ Self Propelled Beast of an electric concrete/asphalt saw built for the pros!

UPDATE 9-14-23 SOLD OUT of this model, but preordered for a shorter lead time, but call 412.447.5400 x 5 for other Electric saws in Patriot’s physical stock. More of this model are pre-ordered also, but see below links for other options in stock:

Core Cut CC3520E3 26″ by Diamond Products Self Propelled Electric Walk Behind Saw • Patriot Contractors Equipment Sales & Supply (

Merit M400-30E 30″ Electric Walk Behind Saw • Patriot Contractors Equipment Sales & Supply (

Husqvarna FS3500E – Electric Self Propelled Walk Behind Concrete Saw #965151829 • Patriot Contractors Equipment Sales & Supply (

Features & Benefits:

  • Frame designed for higher torque from high horsepower engines
  • Forward position motor for more weight at the blade and less on the operator
  • Self propelled
  • Single or three speed models
  • Front pivot allows easy turning
  • Multi-function control handle
Blade CapacityMotor/Engine PowerPower SourceEngine/Motor Make/ModelPart NumberCatalog Number
36”40 HP, 460V-3PHBaldor®ElectricSingle5800439A10497

Made in USA logo - smaller

Solid assortment of blade options in our physical stock also in Diamond Products/Core-Cut, Husqvarna & Norton Diamonds. Simply let us know what you are cutting and our prices are competitive or lower than anyone else on line for the same blade!


Core Cut CC3740E3-36 Brochure(click for pdf)

Maximum depth of cut with 36” blade:14-3/4”
Blade shaft diameter:1-3/4”
Arbor size:1” with drive pin
Blade shaft drive:8 belt
Blade mounting:Right or Left
Blade raise & lower:Electro-hydraulic pump
Transmission:Eaton Model 10
Drive speed:0-200 feet/min
